56K PCI Faxmodem User's Guide and Reference
Installation Instructions
Prepare for installation.
CAUTION: To avoid the risk of electrical
shock, make sure your computer and all peripheral devices are turned off
and unplugged. Disconnect all telephone cables from any existing modems
before opening the computers cover. Touch an unpainted metal area
of your computers case to ground yourself, which protects your equipment
from electrostatic discharge.
NOTE: Before you begin, we recommend
you uninstall any other modems you have in your system. Refer to your
previous modem's documentation for instructions.
Write down your new USRobotics modem's serial number on your Quick
Installation Guide. The serial number is located on the white bar code
sticker on the modem and on the modem's box. If you ever need to call
our Technical Support department, you will need this number, your Product
ID Number, and your Model Number to receive assistance.
The Product ID Number is: USR5660A
The Model Number is: 5660
Step1: Physically install the
modem in your computer.
Turn off your computer and all peripheral devices. Unplug your computer
and remove the computers cover. Remove the expansion slot cover
at the back of an empty PCI expansion slot. PCI slots are usually white
in color. The slot cover is on the back of your computer and covers an
opening on your computers case. The slot cover could be held in
place with a screw or a clip.
Insert the modem into the PCI slot. You may need to rock the modem back
and forth while pressing down firmly to properly seat the modem in the
PCI slot.
The modems metal bracket will cover the opening on the back of
the computer. If applicable, secure the modem with the screw or clip you
removed. Replace the computers cover.
Step 2: Connect the modem to an analog phone line.
Plug one end of the provided phone cord into the jack on the modem labeled
. Plug the other end into
an analog phone wall jack. When you are not using your modem, you can
use a telephone by plugging the telephones cord into the modems
jack.
CAUTION: The USRobotics 56K PCI
Faxmodem requires a standard analog telephone line. Do not connect your
modem to a digital telephone line. Digital lines are commonly used in
office buildings and hotels. If you are unsure whether your line is analog
or digital, ask your network administrator or your local telephone company.
Step 3: Install the modem drivers.
All Operating Systems:
Reconnect your computer and peripherals and turn your computer on.
NOTE: If at any time during the installation
you are prompted to select the location of your installation drivers,
the following is the correct location on the Installation CD-ROM (assuming
D: is your CD-ROM drive).
Windows Me/98/95 drivers - D:\
Windows XP/2000 drivers - D:\2000_XP
Windows 95
Insert the Installation CD-ROM into your CD-ROM drive before Windows opens.
You need to install both the USRobotics V.92 PCI Faxmodem Enumerator
and the USRobotics V.92 PCI Faxmodem.
NOTE: If at any time during the installation
you are prompted to select the location of any installation files, the
location of the files on the Installation CD-ROM is D:\ (assuming D: is
your CD-ROM drive).
When the New Hardware Found or Update Device Driver Wizard appears, follow
the on-screen instructions.
Windows 98
You need to install both the USRobotics V.92 PCI Faxmodem Enumerator
and the USRobotics V.92 PCI Faxmodem.
Log into Windows. Insert the Installation CD-ROM into your CD-ROM drive.
When the Add New Hardware Wizard appears, click Next. Select Search
for the best driver for your device (Recommended) and click Next.
Click Specify a location and type D:\ (If your CD-ROM drive uses
a different letter, type that letter in place of D). Click
Next. When Windows locates the correct drivers for the USRobotics
V.92 PCI Faxmodem Enumerator, click Next. When Windows is finished
installing the drivers, click Finish.
The wizard will then detect and report a search for drivers for U.S.
Robotics V.92 PCI Faxmodem. Click Next. Choose Search for the
best driver for your device (Recommended) and click Next. Click
Specify a location and type D:\ (If your CD-ROM drive uses a different
letter, type that letter in place of D). Click Next.
When Windows locates the correct drivers for the USRobotics V.92 PCI
Faxmodem, click Next. When Windows is finished installing the software,
click Finish.
Windows Me
You need to install both the USRobotics V.92 PCI Faxmodem Enumerator
and the USRobotics V.92 PCI Faxmodem.
Log into Windows. Insert the Installation CD-ROM into your CD-ROM drive.
When the Add New Hardware Wizard appears, select Specify the location
of the driver (Advanced) and click Next. Make sure that Removable
Media (Floppy, CD-ROM...) is not selected. Click Specify a location
and type D:\ (If your CD-ROM drive uses a different letter, type that
letter in place of D). Click Next. When Windows locates
the correct drivers for the USRobotics V.92 PCI Faxmodem Enumerator,
click Next. When Windows is finished installing the drivers, click
Finish.
The wizard will then detect and report a search for drivers for U.S.
Robotics V.92 Faxmodem. Choose Specify the location of the driver (Advanced)
and click Next. Click Specify a location and type D:\ (If
your CD-ROM drive uses a different letter, type that letter in place of
D). Click Next. When Windows locates the correct drivers
for the USRobotics V.92 PCI Faxmodem, click Next. When Windows
is finished installing the software, click Finish.
Windows 2000
Log into Windows. When the Found New Hardware Wizard screen
appears, click Next then insert the Installation CD-ROM into your
CD-ROM drive. Select Search for a suitable driver for my device (Recommended)
and click Next. Click CD-ROM drives and click Next.
When Windows locates the correct drivers for the PCI Simple Communications
Controller, click Next. Click Yes to continue if a Digital
Signature Not Found screen appears*. When Windows is finished installing
the drivers, click Finish.
Windows XP
Log into Windows. When the Found New Hardware Wizard appears, insert your
Installation CD-ROM into your CD-ROM drive. A Hardware Installation
warning may appear*. Click Continue Anyway. When Windows is finished
installing the software, click Finish.
* USRobotics has thoroughly tested in conjunction with
the supported hardware and has verified compatibility with Windows 2000/XP.
Software Installation
Insert the Installation CD-ROM into your CD-ROM drive. The Installation
CD-ROM window should automatically appear.
If your Installation CD-ROM is already in the drive, and the Installation
CD-ROM interface is not displayed, eject and reinsert the Installation
CD-ROM. If the CD-ROM interface still does not appear, click Windows Start
and then Run. Type D:\setup.exe in the Run dialog box.
(If your CD-ROM drive uses a different letter, type that letter in place
of D.)
Install the Instant Update software.
The Instant Update software automatically notifies you of any updates
to your modems code.
To install the Instant Update software:
At the Installation CD-ROM interface, click Software, select
USRobotics Instant Update and then click Install. Then
follow the on-screen instructions to install the Instant Update software.
Install the Internet Call Notification software.
Internet Call Notification enables the V.92 feature Modem On Hold,
which allows your Internet connection to be suspended when there is an
inbound telephone call.
If you are connecting to a service provider that supports V.92, you will
receive a message informing you of an incoming call. In addition, if you
subscribe to Caller ID service, the number of the incoming call will be
displayed in the computer's message window. You will then have the option
to accept the call or to ignore it. If you choose to accept the call,
another message will appear notifying you of the length of time that the
provider's system will wait on hold before the data connection is terminated.
You can then return to the connection when the call is completed without
losing the connection.
If you are connecting to a server that does not support V.92, you will
receive a message informing you of an incoming call. You will then have
the option to accept the call or to ignore it. If you choose to accept
the call, your data connection will be terminated.
To install the Internet Call Notification software:
At the Installation CD-ROM interface, click Software, Internet
Call Notification, and then Install. Follow the on-screen
instructions to complete the installation of the software.
Register your modem.
When you register your modem online, USRobotics will use your information
to:
- Enable your warranty.
- Inform you of future product support notices, alerts, and changes
to our support offerings.
- Invite you to participate in market research, new product definition
studies, and beta test programs.
- Invite you to participate in promotional campaigns.
We respect our customers privacy. USRobotics will not sell or
provide any personal information that identifies you or any individual
to any outside source.
To register your modem:
Connect to your Internet service provider. At the Installation CD-ROM
interface, click Support and then Product Registration.
Click the link to register your modem. You can also register your modem
online at http://www.usr.com/productreg
